VKM-13364
2,00
32,00
34,00
16,00
4,272
13,11
56,090
159,5000
AU
VKM-13628
28,00
30,00
14,00
6,378
11,27
71,860
159,8000
AU
VKM-13365
25,00
27,00
10,00
8,960
7,31
65,510
198,7000
AU
VKM-13367
24,00
26,00
10,00
10,127
7,34
74,420
191,1000
AU
VKM-13368
23,00
25,00
9,00
11,507
6,39
73,580
202,8000
AU
VKM-13370
20,00
22,00
8,00
17,500
5,48
95,970
198,7000
AU
VKM-13372
19,50
21,50
9,00
18,881
6,50
122,800
173,1000
AU
VKM-13375
19,00
21,00
6,00
20,411
3,54
72,280
248,9000
AU
VKM-13376
18,50
20,50
6,00
22,111
3,55
78,610
242,5000
AU
VKM-13379
16,80
18,80
6,70
29,526
4,28
126,500
199,0000
AU
VKM-13380
16,00
18,00
6,00
34,180
3,61
123,700
210,7000
AU
VKM-13381
14,00
16,00
5,50
51,020
3,17
161,500
201,3000
AU
VKM-13382
13,00
15,00
5,00
62,723
2,66
169,700
206,4000
AU
VKM-13385
12,50
14,50
4,80
71,680
2,48
177,800
206,4000
AU
VKM-13387
12,00
14,00
4,50
81,019
2,18
177,200
211,3000
AU
VKM-13390
10,00
12,00
3,80
140,000
1,52
212,700
208,7000
AU
VKM-13391
9,00
11,00
3,40
192,044
1,13
217,700
209,9000
AU
VKM-13395
8,70
10,70
3,30
212,603
1,04
220,400
209,1000
AU
VKM-12344
8,00
10,00
3,10
273,438
0,85
232,800
204,5000
AU
VKM-13396
2,20
35,80
38,00
18,00
4,467
14,84
66,330
191,6000
AW
VKM-12346
32,80
35,00
16,00
5,809
12,94
75,160
197,5000
AW
VKM-12348
29,80
32,00
15,00
7,746
12,09
93,660
191,4000
AW
VKM-12350
27,80
30,00
14,00
9,540
11,10
105,900
192,0000
AW
VKM-13672
26,00
28,20
12,00
11,662
9,13
106,600
208,9000
AW
VKM-12352
23,80
26,00
11,00
15,204
8,28
125,900
207,4000
AW
VKM-13397
21,80
24,00
10,00
19,785
7,23
143,100
210,9000
AW
VKM-13673
20,00
22,20
8,00
25,622
5,29
135,500
240,5000
AW
VKM-12354
17,80
20,00
7,50
36,345
4,86
176,800
228,2000
AW
VKM-13629
16,80
19,00
6,80
43,229
4,17
180,400
237,6000
AW
VKM-13674
14,80
17,00
5,60
63,229
3,03
191,900
252,9000
AW
VKM-13398
12,80
15,00
4,00
97,739
1,46
142,600
305,5000
AW
VKM-12356
10,80
13,00
3,80
162,715
1,29
210,600
272,0000
AW
VKM-13399
8,80
11,00
3,40
300,781
0,92
277,000
248,5000
AW
179
Stainless steel no. 1.4310
(A301, BS 301S21)
Length 1000 mm
Endless compression springs
Sales catalog springs 0049 (0)7123 960-192 · Sales customize springs 0049 (0)7123 960-193 · Offers 0049 (0)7123 960-197 · Fax 0049 (0)7123 960-195
article
number
d
wire
diameter
D
mean
coil
diameter
De
outer
coil
diameter
s
pitch/distance
from mid-wire to
mid-wire
R1
spring rate from
one active coil
N/mm
sn1
maximum spring
deflection of
one coil
Fn
maximum
possible spring
force
weight
one spring
in gram
price
group
