KM-3364
2,00
32,00
34,00
16,00
4,974
13,11
65,310
158,5000
AR
KM-3628
28,00
30,00
14,00
7,425
11,27
83,670
158,8000
AR
KM-3365
25,00
27,00
10,00
10,432
7,31
76,270
197,5000
AR
KM-3367
24,00
26,00
10,00
11,791
7,34
86,640
189,9000
AR
KM-3368
23,00
25,00
9,00
13,397
6,39
85,660
201,5000
AR
KM-3370
20,00
22,00
8,00
20,375
5,48
111,700
197,5000
AR
KM-3372
19,50
21,50
9,00
21,983
6,50
143,000
172,0000
AR
KM-3375
19,00
21,00
6,00
23,764
3,54
84,160
247,4000
AR
KM-3376
18,50
20,50
6,00
25,744
3,55
91,530
241,0000
AR
KM-3379
16,80
18,80
6,70
34,376
4,28
147,300
197,7000
AR
KM-3380
16,00
18,00
6,00
39,795
3,61
144,000
209,3000
AR
KM-3381
14,00
16,00
5,50
59,402
3,17
188,100
200,0000
AR
KM-3382
13,00
15,00
5,00
74,192
2,66
197,500
205,1000
AR
KM-3385
12,50
14,50
4,80
83,456
2,48
207,000
205,1000
AR
KM-3387
12,00
14,00
4,50
94,329
2,18
206,300
209,8000
AR
KM-3390
10,00
12,00
3,80
163,000
1,52
247,700
207,3000
AR
KM-3391
9,00
11,00
3,40
223,594
1,13
253,500
208,6000
AR
KM-3395
8,70
10,70
3,30
247,531
1,04
256,600
207,8000
AR
KM-2344
8,00
10,00
3,10
318,359
0,85
271,000
203,2000
AR
KM-3396
2,20
35,80
38,00
18,00
5,201
14,84
77,230
190,4000
AR
KM-2346
32,80
35,00
16,00
6,763
12,94
87,510
196,2000
AR
KM-2348
29,80
32,00
15,00
9,018
12,09
109,000
190,2000
AR
KM-2350
27,80
30,00
14,00
11,108
11,10
123,300
190,8000
AR
KM-3672
26,00
28,20
12,00
13,578
9,13
124,100
207,6000
AR
KM-2352
23,80
26,00
11,00
17,702
8,28
146,500
206,1000
AR
KM-3397
21,80
24,00
10,00
23,305
7,23
166,600
209,6000
AR
KM-3673
20,00
22,20
8,00
29,831
5,29
157,800
238,9000
AR
KM-2354
17,80
20,00
7,50
42,615
4,86
205,900
226,8000
AR
KM-3629
16,80
19,00
6,80
50,330
4,17
210,100
236,1000
AR
KM-3674
14,80
17,00
5,60
73,616
3,03
223,500
251,3000
AR
KM-3398
12,80
15,00
4,00
113,796
1,46
166,000
303,6000
AR
KM-2356
10,80
13,00
3,80
189,447
1,29
245,200
270,3000
AR
KM-3399
8,80
11,00
3,40
350,195
0,92
322,500
247,0000
AR
178
article
number
d
wire
diameter
D
mean
coil
diameter
De
outer
coil
diameter
s
pitch/distance
from mid-wire to
mid-wire
R1
spring rate from
one active coil
N/mm
sn1
maximum spring
deflection of
one coil
Fn
maximum
possible spring
force
weight
one spring
in gram
price
group
Music wire EN 10270-1-SH
(A228, BS 5216)
Length 1000 mm
Endless compression springs
