VD-288O-10 2,80
17,20
20,00
0,35 13,70 20,90
18,50
0,60 46,976
2,25
12,90 5,60 0,00 263,063 31,00 13,40 3,00 239,576 30,70 11,1777 O
VD-288P
27,20
0,66 30,199
3,50
16,93 10,27 0,00 309,998 28,46 17,70 3,55 286,887 28,05 14,4653 O
VD-288Q
39,50
0,90 19,217
5,50
23,41 16,09 0,00 309,174 25,64 24,62 5,60 285,953 25,23 19,7254 O
VD-288R
64,20
1,40 11,126
9,50
36,37 27,83 0,00 309,680 23,49 38,46 9,65 286,378 23,09 30,2456 P
VD-288S
101,00
2,13 6,819
15,50
55,80 45,20 57,29 308,244 22,29 59,20 15,85 285,036 21,89 46,0259 Q
VD-288S-04
16,10
18,90
0,35 12,60 20,00
27,50
0,70 36,821
3,50
16,87 10,63 0,00 391,406 32,20 18,20 4,00 342,434 31,50 13,5402 P
VD-288S-10
65,00
0,96 19,827
6,50
43,20 21,80 0,00 432,221 32,40 47,85 4,37 340,027 31,00 20,9258 Q
VD-288T
14,20
17,00
0,30 10,80 18,00
33,00
0,76 34,152
5,50
23,13 9,87 0,00 336,937 36,00 24,20 4,12 300,535 35,37 16,2849 N
VD-288T-02
12,20
15,00
0,30 8,80 15,70
25,00
0,58 65,819
4,50
19,82 5,18 0,00 341,018 50,09 20,63 2,77 287,627 49,16 12,1258 P
VD-288T-03
32,00
0,71 49,364
6,00
24,56 7,44 0,00 367,346 48,60 25,64 3,41 313,954 47,67 14,9240 P
VD-288T-04
38,00
0,80 42,312
7,00
27,72 10,28 0,00 435,045 48,24 28,98 3,12 381,653 47,30 16,7895 P
VD-288T-05
44,00
0,94 34,845
8,50
32,46 11,54 0,00 402,191 45,15 33,99 4,29 348,799 44,22 19,5878 P
VD-288T-06
51,00
1,03 31,177
9,50
35,62 15,38 0,00 479,584 45,77 37,60 3,46 417,774 44,84 21,4533 Q
VD-288T-07
64,00
1,30 23,695
12,50
45,10 18,90 0,00 447,908 43,72 47,35 5,27 394,516 42,79 27,0498 Q
VD-288T-08
76,00
1,53 19,746
15,00
53,00 23,00 48,33 454,226 43,51 55,69 6,15 401,032 42,58 31,7136 Q
VD-288T-09
89,00
1,75 16,925
17,50
60,90 28,10 67,40 475,664 42,83 64,30 6,50 418,042 41,90 36,3773 Q
VD-288T-10
102,00
1,98 14,809
20,00
68,79 33,21 84,00 491,743 43,05 79,95 10,90 326,542 42,11 41,0411 R
VD-288U
11,20
14,00
0,25 7,70 14,70
20,50
0,45 109,375
3,50
16,62 3,88 0,00 424,900 64,82 17,23 1,51 357,656 63,66 9,4193 O
VD-288V
29,00
0,62 69,602
5,50
22,91 6,09 0,00 423,906 57,83 23,87 2,37 357,060 56,66 12,8445 O
VD-288W
45,90
0,96 40,296
9,50
35,50 10,40 0,00 419,143 52,38 37,15 4,16 352,590 51,22 19,6948 O
VD-288X
71,40
1,47 24,698
15,50
54,38 17,02 46,00 420,313 49,47 57,07 6,75 353,916 48,31 29,9704 P
VD-288X-02 2,90
16,50
19,40
0,35 12,90 20,40
25,00
0,53 50,097
2,75
15,65 9,35 0,00 468,411 40,08 17,65 1,84 368,216 38,27 12,8556 O
VD-288X-03
32,00
0,65 36,738
3,75
19,25 12,75 0,00 468,411 37,65 21,95 1,49 369,218 35,13 15,5621 O
VD-288X-04
38,00
0,74 30,615
4,50
22,70 15,30 0,00 468,411 35,66 25,90 3,02 370,443 33,69 17,5919 O
VD-288X-05
44,00
0,92 22,961
6,00
25,78 18,22 0,00 418,243 32,45 27,85 3,96 370,825 31,93 21,6516 O
VD-288X-06
51,00
0,98 21,195
6,50
28,95 22,05 0,00 467,351 32,84 33,50 4,33 370,914 31,60 23,0048 Q
VD-288X-07
64,00
1,18 16,699
8,25
35,95 28,05 0,00 468,411 32,36 41,80 5,49 370,721 30,18 27,7411 Q
VD-288X-08
76,00
1,33 14,502
9,50
43,65 32,35 0,00 469,136 32,18 50,60 6,29 368,348 29,64 31,1242 Q
VD-288X-09
89,00
1,56 11,980
11,50
49,95 39,05 31,30 467,812 31,16 58,20 7,61 368,979 28,98 36,5371 R
VD-288X-10
102,00
1,91 9,501
14,50
54,10 47,90 64,00 455,139 29,07 63,00 9,58 370,548 28,55 44,6564 R
VD-288X-11
115,00
2,05 8,747
15,75
61,45 53,55 83,79 468,411 29,70 72,90 10,41 368,256 29,29 48,0395 S
VD-288X-12
127,00
2,29 7,762
17,75
66,55 60,45 99,88 469,187 29,27 79,30 11,73 370,227 27,89 53,4524 S
VD-288X-13
153,00
2,63 6,639
20,75
82,50 70,50 131,50 468,079 29,59 97,30 13,73 369,816 27,56 61,5718 S
112
Sales catalog springs 0049 (0)7123 960-192 · Sales customize springs 0049 (0)7123 960-193 · Offers 0049 (0)7123 960-197 · Fax 0049 (0)7123 960-195
Compression springs
Stainless steel
X10CrNi188
no.
1.4310
(A301, BS 301S21)
static
dynamic
d
wire
dia-
meter
D
mean
coil
diameter
De
outer
coil
diameter
Detol
+/-
tolerance
De
Dd
mandrel
diameter
up
to
Dh
bush
diameter
from
L0
free
length
L0tol
+/-
tolerance
L0
R
spring
rate
N/mm
n
acti
v
e
coils
Ln
minimum
spring
length
sn
maximum
spring
deflection
Lk
buckling
length
Fn
maximum
force
at
Ln
Fntol
+/-
tolerance
Fn
Lndyn
minimum
length
dynamic
shdyn
maximum
stroke
dynamic
Fndyn
maximum
force
dynamic
Fndtol
+/-
tolerance
Fndyn
weigth
one spring
in gram
price
group
article
number
