Z-162U-32I
3,00 24,00
0,35 28,90 180,00 36,00
154,00
2,00 124,50 14,75 27,500 348,500 19,10 2,200 299,94 145,94 155,9000
ZO
Z-162U-32X
270,00 36,00
154,00
2,00 125,25 14,37 27,500 348,500 19,10 2,187 300,84 146,84 156,8000
ZO
Z-162U-33I
180,00 38,00
172,00
2,50 142,50 14,75 27,500 348,500 18,77 1,916 339,56 167,56 177,9000
ZP
Z-162U-33X
270,00 38,00
172,00
2,50 143,25 14,37 27,500 348,500 18,75 1,906 340,46 168,46 178,9000
ZP
Z-162U-34I
180,00 41,00
193,00
2,50 163,50 14,75 27,500 348,500 18,46 1,665 385,78 192,78 203,6000
ZS
Z-162U-34X
270,00 41,00
193,00
2,50 164,25 14,37 27,500 348,500 18,46 1,658 386,68 193,68 204,5000
ZS
Z-162U-35I
180,00 44,00
217,00
2,50 187,50 14,75 27,500 348,500 18,26 1,449 438,53 221,53 233,2300
ZS
Z-162U-35X
270,00 44,00
217,00
2,50 188,25 14,37 27,500 348,500 18,26 1,443 439,51 222,51 234,1500
ZS
Z-162U-36I
180,00 47,00
241,00
2,50 211,50 14,75 27,500 348,500 18,09 1,282 491,43 250,43 262,7300
ZT
Z-162U-36X
270,00 47,00
241,00
2,50 212,25 14,37 27,500 348,500 18,09 1,272 492,33 251,33 263,6500
ZT
Z-162U-38I
18,00
0,30 23,40 180,00 19,00
60,50
1,10
40,50 10,00 43,800 452,600 36,70 19,560 81,40 20,90 37,5300
ZM
Z-162U-38X
270,00 19,00
60,50
1,10
41,25
9,63 43,800 452,600 36,70 19,170 81,80 21,30 38,1900
ZM
Z-162U-39I
180,00 23,00
86,00
1,50
64,50 10,75 43,800 452,600 35,20 11,930 120,30 34,30 58,6000
ZN
Z-162U-39X
270,00 23,00
86,00
1,50
65,25 10,38 43,800 452,600 35,20 11,780 120,70 34,70 59,2600
ZN
Z-162U-40I
180,00 28,00
105,50
2,00
85,50 10,00 43,800 452,600 34,50 8,891 151,49 45,99 77,0400
ZN
Z-162U-40X
270,00 28,00
105,50
2,00
86,25
9,62 43,800 452,600 34,50 8,811 151,90 46,40 77,7000
ZN
Z-162U-41I
180,00 31,00
123,50
2,00 103,50 10,00 43,800 452,600 34,30 7,299 179,52 56,02 92,8400
ZO
Z-162U-41X
270,00 31,00
123,50
2,00 104,25
9,62 43,800 452,600 34,30 7,244 179,94 56,44 93,5000
ZO
Z-162U-42I
180,00 34,00
144,50
2,00 124,50 10,00 43,800 452,600 33,90 6,037 212,22 67,72 111,2800
ZP
Z-162U-42X
270,00 34,00
144,50
2,00 125,25
9,62 43,800 452,600 33,90 6,000 212,64 68,14 111,9400
ZP
Z-162U-43I
180,00 36,00
162,50
2,50 142,50 10,00 43,800 452,600 33,32 5,258 240,26 77,76 127,0800
ZQ
Z-162U-43X
270,00 37,00
162,50
2,50 143,25
9,62 43,800 452,600 33,29 5,230 240,68 78,18 127,7400
ZQ
Z-162U-44I
180,00 39,00
183,50
2,50 163,50 10,00 43,800 452,600 32,72 4,570 272,96 89,46 145,5200
ZR
Z-162U-44X
270,00 39,00
183,50
2,50 164,25
9,62 43,800 452,600 32,70 4,549 273,38 89,88 146,1800
ZR
Z-162U-45I
180,00 42,00
207,50
2,50 187,50 10,00 43,800 452,600 32,33 3,976 310,34 102,84 166,6000
ZS
Z-162U-45X
270,00 42,00
207,50
2,50 188,25
9,62 43,800 452,600 32,32 3,960 310,76 103,26 167,2500
ZS
Z-162U-46I
180,00 45,00
231,50
2,50 211,50 10,00 43,800 452,600 31,99 3,520 347,72 116,22 187,8000
ZT
Z-162U-46X
270,00 45,00
231,50
2,50 212,25
9,62 43,800 452,600 31,98 3,505 348,14 116,64 188,5000
ZT
Z-163I
3,20 43,20
0,60 48,60 180,00 25,00
100,00
1,80
40,00 30,00 11,880 238,400 16,03 1,451 256,13 156,13 105,8800
ZM
Z-163X
270,00 26,00
100,00
1,80
40,80 29,60 11,880 238,400 15,92 1,421 259,52 159,52 107,8800
ZM
Z-164I
180,00 37,00
142,00
2,40
81,60 30,20 11,880 238,400 13,41 0,681 474,62 332,62 209,7700
ZO
Z-164X
270,00 37,00
142,00
2,40
82,40 29,80 11,880 238,400 13,38 0,674 478,02 336,02 211,7700
ZO
Z-165I
180,00 47,00
180,00
3,00 129,60 30,20 11,880 238,400 12,39 0,423 715,50 535,50 329,6500
ZU
Federstahldraht
EN
10270-1-SH
Zugfedern
Bestell-
nummer
d
Draht-
stärke
De
Äußerer
Durch-
messer
Detol
+/-
Toleranz
De
Ösen-
stellung
Grad
Dh
Hülse
ab
L0
unge-
spannte
Länge
L0tol
+/-
Toleranz
L0
R
Feder-
rate
N/mm
Lk
Länge des
Feder-
körpers
sn
Größter
Feder-
weg
Lh
Ösen-
höhe
Fn
Größte
Kraft bei
Ln
Fntol
+/-
Toleranz
Fn
F0
Vor-
spannung
Gewicht
per Stück
in Gramm
Preis-
gruppe
+/-
Toleranz
Ösen-
stellung
Ln
Größte
Feder-
länge
